SPECIFICATIONS (Fonte www.rigpix.com)

Type:    Amateur VHF/UHF transceiver

Frequency range:    TX: 144-146 / 430-440 / 1260-1300 MHz

                                RX: 0.531-1300 MHz

Mode:    TX: FM/NFM

              RX: AM/FM/NFM/WFM

RF Power output:    Hi: 5/4.5/1 W (@ 9 VDC)

                                Mid1: 2/2/0.2 W

                                Mid2: 0.8/0.8/0.2 W

                                Lo: 0.2/0.2/0.2 W

Receiver system:    Single conversion superheterodyne (WFM)

                                IF: 10.7 MHz

                                Dual conversion superheterodyne (AM/FM/NFM)

                                1st IF: 50.65 and 50.75 MHz

                                2nd IF: 450 KHz

Sensitivity:    N/A

Selectivity:    AM/FM: 12 KHz (-6 dB), 35 KHz (-60 dB)

                     WFM: 130 KHz (-6 dB), 300 KHz (-60 dB)

Image rejection:    60 dB

Voltage:    7.4 VDC (Li-Ion pack)

                 6 VDC (4*R6/AA)

                 4.5-16 VDC external

Current drain:    RX: 200 mA

                          TX: Max 2 A

Impedance:    50 ohms, SMA

Dimensions (W*H*D):    61*106*38 mm

Weight:    296 gr

Manufactured:    2009-20xx

Other:

1000 memories. CTCSS/DCS with tone scan. VOX. Ferrite bar for MW reception. Twin RX

Eham.net review:

Alinco DJ-G7
