SPECIFICATIONS (Fonte: www.rigpix.com)

GENERAL

Type:    HF/VHF/UHF receiver/scanner

Frequency range:    0.1-2600 MHz (Cellular blocked in the US)

Tuning steps:

20/100/500 Hz and 1/5/6.25/9/10/12.5/20/25/50/100/500 KHz

Mode:    AM/NAM/WAM/NFM/WFM/SSB/CW

Channels/memory management:

2000 regular in up to 100 groups

50 band edge (PMS)

5 preset (PS)

Power supply:    13.5 VDC ±15%

Current drain/power consumption:    Max 0.7 A

Antenna impedance/connector:    50 ohms, SO-239

                                                    450 ohms, spring terminals

Dimensions (W*H*D):    180*70*203 mm (7.1*2.8*8")

Weight:    1.9 Kg (4.2 lbs)

Other features:

Real-time band-scope, world clock. NB. VCS. Alpha tags.

CAT computer control. 10.7 MHz IF output. Dual RX with

sub VFO within ±20 MHz of main VFO.

RECEIVER SECTION

Sensitivity:

    AM (10 dB S/N)

        0.2-0.5 MHz: 10.8 uV

        0.5-1.8 MHz: 4 uV

        1.8-4 MHz: 2.5 uV

        4-30 MHz: 1.1 uV

    NFM (12 dB SINAD)

        28-30 MHz: 0.35 uV

        30-2000 MHz: 0.45 uV

        2000-2600 MHz: 0.8 uV

    WFM (12 dB SINAD)

        30-2000 MHz: 1.5 uV

    SSB/CW (10 dB S/N)

        0.2-0.5 MHz: 4.8 uV

        0.5-1.8 MHz: 1 uV

        1.8-4 MHz: 0.6 uV

        4-30 MHz: 0.3 uV

        30-2000 MHz: 0.3 uV

        2000-2600 MHz: 0.5 uV

AF output power/speaker:    1 W at ?% distortion / 8 ohms

External speaker connector:    3.5 mm, 8 ohms

MISCELLANEOUS

Manufactured:    Japan, 2000-2010 (Discontinued)
